Heat Cure Adhesives & Sealants - Non-Sag (Thixotropic)

United Adhesives' heat cure non-sag (thixotropic) version adhesives and sealants made from high performance silicones and epoxies provide following major features:

-                Strong bonding to aluminum and most common metals.

-                Strong bonding to most common plastics.

-                Thermal stress compliant with silicone adhesives.

-                Automated dispensable

-                Non-corrosion sealants and adhesives

-                Excellent moisture, oil and chemical resistance

They are used to bond and seal electronic devices, components, electrical equipment, power and control connections, cover plates, housings, etc. The silicone series, Bondseal, provides stress release and resistance to high temperature and humidity. The epoxy series provides strong structural bonding for vibration applications and resistance to oil and chemicals.

Click the name of the adhesive in following Table to access its technical datasheet (TDS) in PDF file.



Name

BondSeal
BS8460

BondSeal
BS8350

BondSeal
BS8311

BondSeal
BS8440

EP1611

EP1641

Chemical Base

Silicone

Silicone

Silicone

Silicone

Flexible Epoxy

Epoxy

Features / Advantages

Heat cure to form silicone rubber. Non-corrosion Non-slump. Strong bonding to Al and most plastics.

One part. Non-slump. Heat cure to form silicone rubber. Strong bonding to Al and most plastics.

One Part flowable. Heat cure to form silicone rubber. Non-corrosion sealant / adhesive. Strong bonding to Al and most plastics.

Two part. Heat cure to form silicone rubber. Non-corrosion sealant / adhesive.

Flexible epoxy formulation. Two part for fast cure. Room temperature curable.

Very Low CTE. Thixotropic (non-sag) epoxy. Strong oil and chemical resistance.

Typical Application

Bonding & sealing electronic devices, components, equipment, power control connections, cover plates, etc. Stress release & resist. to high temp & humidity

Bond & seal electronic devices. Good oil resistance. Seal lead, housing. Attach baseplate; Gasketing; Connector seal.

Bonding & sealing electronic devices, components, electrical equipment, power control connections, cover plates, etc. Stress release & resist. to high temp & humidity

Bond & seal electronic devices. Good oil resistance. Seal lead, housing. Attaching baseplate; Gasketing; Connector seal.

For low stress bonding & flexible seal. Bond to PBT, PPS, Nylon, PC, Phenolics and other difficult materials.

For applications that require extremely low CTE bonding such as silicon / ceramic bonding, ignition coil potting.

Rheology

Thixotropic
(non-sag)

Thixotropic
(non-sag)

Flowable

Flowable

Flowable, Dispensable

Thixotropic
(non-sag)

Appearance / Color

White / Grey

White / Grey

White / Grey

White / Grey

Off-white

Milky White Brown
Or Grey

Part / Component

A : B = 1 : 1

One Part

One Part

A : B = 1 : 1

Two

One Part

Viscosity @25C (cps, after mixing)

122,000

110,000

45,000

40,000

60,000

160,000

Pot life (hr)

2 hrs

N/A

N/A

2 hrs

30 min

8 hrs

Cure Rate

125C 60 min

125C 60 min

125C 60 min

rmT 12 hrs
125C 15 min

rmT 12 hrs
85C 60 min

125C 45 min

Weight Loss @250C 1hr

< 0.2%

< 0.2%

< 0.2%

< 0.2%

< 0.5%

< 0.2%

Storage

< 25C

< 4C

< 4C

< 25C

< 25C

< – 40C

Shelf Life (days)

12 month @ 24C

>3 months @ 4C

6 months @ 4C

12 month @ 24C

12 month @ 24C

> 3 months @ –40C

Thermal Stability

-40C to 180

-40C to 180

-40C to 180

-40C to 180

150C

-40C to 180

Tg

-120C

-120C

-120C

-120C

35C

120

CTE (ppm/C)

< 250

< 250

N/a

N/a

350

65 (above Tg)
18 (below Tg)

Hardness

Shore A = 60

Shore A = 62

Shore A = 47

Shore A = 51

Shore A = 60

7.8 Gpa

Tensile Strength

6 Mpa

5.8 Mpa

5.2 Mpa

5.8 Mpa

8 Mpa

N/a

Elongation

180%

250%

280%

240%

150%

N/a

Adhesion (Al/Al Lap Shear, psi)

> 500 psi

550 psi

> 600 psi

> 550 psi

> 400 psi

> 1800 psi





*Chemicals: Windshield washer 25C, 1hr; Brake fluid 25C 1hr; Antifreezer & Coolant 50C 1hr; Moto oil 50C 1hr; Transmission fluid 25C 1hr; Ethyl alcohol 25C 1hr.
